301-08 - Single and Poly-phase Metering
Learning objectives
- State the purpose of the watt-hour meter
- List the units of measurement used in revenue metering
- Identify the electrical and mechanical principles of meter operation
- Explain meter constants and their purpose
- State the differences in single and three phase construction
- Explain Blondelrs Theorem
- Explain the purpose of calibrating single and poly-phase meters
- Explain the difference between as-found and as-left information
- Demonstrate inspection and maintenance procedures for single-phase and poly-phase meters
- Explain the process of calibrating a single phase meter
- Explain the process of calibrating a poly-phase meter
- Identify the function of a solid-state digital meter
- Explain the purpose of the rotating standard
- Locate requirements pertaining to use of a rotating standard
- Perform a digital meter calculation
- Demonstrate applications for load profile data
Course overview
Single- and poly-phase metering are the two types of revenue data meters used in the modern world. Technology advances change the designs of meters that may be applied at the service entrance. Still, the purpose, data, and terminology data remain the same. Understanding this information better prepares a technician to service meters today and tomorrow.
The Single- and Poly-phase Metering training course describes the process for meter reading, testing, and calibration. This online course discusses:
- Watt-hour meter purpose and operation
- Meter types
- Understanding meter constants
- Poly-phase circuit metering
- Meter reading, testing, and calibration
- Rotating standard guidelines
Single- and Poly-phase Metering is part of the Distribution Systems training series.
- 35 minutes
- Format: Online Interactive
- English
